260 Ton Terrain Crane
All Terrain Crane
XCMG XCA250
Max. load capacity(t): 260
Telescopic boom(m): 88
Number of axles: 5
260 Ton Terrain Crane
Max. load capacity(t): 260
Telescopic boom(m): 88
Number of axles: 5
The five-axle, dual-engine all-terrain crane XCA250_K features an extra-long boom delivering exceptional performance. It is ideally suited for diverse applications, including urban construction installation, tower crane assembly and disassembly, bridge construction, and equipment installation.
PARAMETERS
| Item | Unit | Parameter |
|---|---|---|
| Max. load capacity | t | 260 |
| Telescopic boom | m | 88 |
| Number of axles | – | 5 |
| Max. hoist height | m | 115 |
| Max. load moment | kN.m | 6586 |
| Drive engine model | – | OM471LA.E5-1 |
| Drive engine power | kw | 390 |
| Drive/Steering | – | 10×8 |
| Driving speed | km/h | 60 |
| Dead Weight in Travel State | kg | 70800 |
| Dimensions | mm | 17280×3000×4050 |
| Emission standard | – | EU Stage V、EPA /CARB Tier 4 final |
