50 Ton Terrain Crane
Truck Crane
XCT50_Y
Max. load capacity(t): 50
Telescopic boom(m): 44.5
Number of axles: 4
50 Ton Terrain Crane
Max. load capacity(t): 50
Telescopic boom(m): 44.5
Number of axles: 4
Optimal design of the XCR50_E shows strong adaptability in driving and lifting in confined and height-restricted spaces. The extra-large and comfortable cab, combined with the intelligent auxiliary system, ensures economical operation and more worry-free lifting.
PARAMETERS
| Item | Unit | Parameter |
|---|---|---|
| Max. load capacity | t | 50 |
| Telescopic boom | m | 37.4 |
| Number of axles | – | 2 |
| Max. hoist height | m | 45.7 |
| Max.load moment | kN.m | 1464 |
| Drive engine model | – | Cummins B6.7 |
| Drive engine power | kw | 168 |
| Drive/Steering | – | 4×4×4 |
| Driving speed | km/h | 25 |
| Dead Weight in Travel State | kg | 31000 |
| Dimensions | mm | 11331×2543×3421 |
| Emission standard | – | EU Stage V |
